| Type | CMOS Sensor |
| Pixels | Effective: Approx. 20.2 megapixels |
| Aspect Ratio | 3:2 (Horizontal: Vertical) |
| FOCUSING | |
| AF Point | 11 points |
| Center | cross-type at f/5.6; vertical line-sensitive at f/2.8 |
| Upper and lower AF points | vertical line-sensitive AF at f/5.6. |
| Other AF points | Horizontal line-sensitive AF at f/5.6. |
| Modes | Autofocus ,Manual focus. |
1 )Autofocus | - One-Shot AF - AI Servo AF - AI Focus AF (Switches between One-Shot AF and AI Servo AF automatically) |
| LCD MONITOR | |
| Type | TFT color, liquid-crystal monitor |
| STORAGE | |
| Storage Type | SD card, SDHC card, SDXC memory card |
| FLASH | |
| Built-in Flash | Yes |
| Red-Eye Reduction | Yes |
| External Flash Compatibility | Yes |
| POWER SOURCE | |
Batteries | One Battery Pack LP-E6 With the AC Adapter Kit ACK-E6, AC power is possible. With Battery Grip BG-E13, two battery packs. (LP-E6) can be used. Or six AA-sized/LR6 batteries can be used |
| PHYSICAL SPECIFICATIONS | |
| Dimensions (W x H x D) | Approx. 5.7 x 4.4 x 2.8 in./ 144.5 x 110.5 x 71.2mm |
Weight (Body Only) | Approx. 26.7 oz. / 755g (CIPA standard) Approx. 24.0 oz. / 680g (Body only) |
| FILE TYPE | |
| Image Type | CMOS Sensor |
| Image Size (1) Large | Approx. 20.0 megapixels (5,472 x 3,648) |
| (2) Medium | Approx. 8.9 megapixels (3,648 x 2,432) |
| (3) Small 1 | Approx. 5.0 megapixels (2,736 x 1,824) |
| (4) Small 2 | Approx. 2.5 megapixels (1920 x 1280) |
| (5) Small 3 | Approx. 350,000 pixels (720 x 480) |
| (6) RAW | Approx. 20.0 megapixels (5,472 x 3,648) |
| M RAW | Approx. 11.0 megapixels (4,104 x 2,736) |
| S RAW | Approx. 5.0 megapixels (2,736 x 1,824) |
| SHOOTING | |
| Color Space | sRGB, Adobe RGB |
| Continuous Shooting | Max. approx. 4.5 fps Silent continuous shooting: Max. approx. 3.0 fps |
Shutter Speed | 1/4000 to 30 sec., X-sync at 1/180 sec. (Total shutter speed range. Available range varies by shooting mode.) |
| EXPOSURE CONTROL | |
| Metering Modes | Max. aperture TTL metering with 63-zone SPC with the |
following selectable modes | 1) Evaluative metering. 2) Partial metering (center: approx. 8% of viewfinder) 3) Spot metering (center: approx. 3.5% of viewfinder) 4) Center-weighted average metering. |
