Brand | Hikvision |
Model | DS-7632NI-K2 |
Type | 4K NVR |
Video Compression/Format | H.265/ H.265+/ H.264/ H.264+/ MPEG4 |
Video Output (VGA) | 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Output (HDMI) | 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Recording Res. | 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
Max. Video Recording Res. | 3840 x 2160 |
IP Video Input | 32 Channel |
Audio Output Channel | 1-channel, RCA (Linear, 1K omega) |
Two way Audio | 1-channel, RCA (2.0 Vp-p, 1K omega) |
Decoding Capability | 8-channel, 1080p (30fps) |
Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
Number HDD Interface (SATA) | 2 SATA |
Max HDD Support (GB,TB) | Up to 6TB capacity for each HDD |
Max. Storage Support | 12TB |
Network Interface (RJ45) | 1, RJ-45 10M/100M/1000M self-adaptive Ethernet interface |
USB Port | 1 x USB3.0, 1 x USB2.0 |
Incoming Bandwidth | 256 Mbps |
Outgoing Bandwidth | 160 Mbps |
Chassis | 385 mm |
Power Supply | 12VDC |
Power Consumption | <-15 W |
Max. Power | <-40W |
Dimensions | 385 x 315 x 52mm |
Weight (Kg) | <-1 kg |
Warranty | 1 year |
- 32-ch 1U 4K NVR
- Up to 32 channel IP cameras can be connected.
-Supports decoding H.265+/H.265/H.264+/H.264 video formats.
- Up to 4K high-definition live view, storage and playback.
- Up to 8-ch @ 1080p decoding capacity.
- Up to 256 Mbps high incoming bandwidth ensures IP cameras can be connected.
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output.
- 2 HDDs for continuous video recording.
