Brand | Hikvision |
Model | DS-9632NI-I16 |
Type | 4K NVR |
Video Output (VGA) | 2K (2560 x 1440), 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768 |
Video Output (HDMI) | 4K (3840 x 2160), 2K (2560 x 1440), 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768 |
Video Recording Res. | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
Max. Video Recording Res. | 3840 x 2160 |
IP Video Input | 32-channel |
Audio Output Channel | 2-channel, RCA (2.0 Vp-p, 1K omega) |
Two way Audio | 1-channel, RCA (2.0 Vp-p, 1K omega) |
Live View / Playback Resolution | 12MP/8MP/6 MP/5MP/4 MP/3MP/1080p/UXGA/720p / VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Synchronous Playback | 16-channel |
Number HDD Interface (SATA) | 16 SATA |
Max HDD Support (GB,TB) | Up to 6TB capacity for each disk |
Max. Storage Support | 96TB |
Network Interface (RJ45) | 2, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
Serial Interface | RS-232, RS-485, keyboard |
USB Port | 1 x USB3.0, 2 x USB2.0 |
Remote Connections | 128 |
Incoming Bandwidth | 320 Mbps |
Outgoing Bandwidth | 256 Mbps |
Array Type | RAID0, RAID1, RAID5, RAID6, RAID10 |
Number of Arrays | 4 |
Chassis | 19-Inch rack-mounted 2U chassis |
Power Supply | 100 - 240VAC, 50 - 60Hz |
Power Consumption | <-45 W |
Max. Power | 300 W |
Dimensions | 445 x 496 x 146mm |
Weight (Kg) | <-12.5Kg |
Warranty | 1year |
- Max. Storage Support 96TB.
- Video Recording Res. 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF.
- Number HDD Interface (SATA) 16 SATA.
