Brand | Hikvision |
Model | DS-7608NI-Q1 |
Type | 08 Channel NVR |
Video Compression/Format | H.265/ H.265+/ H.264/ H.264+/ MPEG4 |
Video Output (VGA | 1920 x 1080p/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Output (HDMI) | 4K (3840 x 2160)/30Hz, 1920 x 1080/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Recording Res. | 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
Max. Video Recording Res. | 3840 x 2160 |
IP Video Input | 8-channel, Up to 8 MP resolution |
Audio Output Channel | 1-channel, RCA (Linear, 1K omega) |
Two way Audio | 1-channel, RCA (2.0 Vp-p, 1K omega) |
Live View / Playback Resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
Decoding Capability | 1-channel, 8 MP / 4-channel, 1080p |
Synchronous Playback | 8-channel |
Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
Number HDD Interface (SATA) | 1 SATA |
Max HDD Support (GB,TB) | Up to 6TB capacity for each disk |
Max. Storage Support | 6TB |
Network Interface (RJ45) | 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
USB Port | 2 x USB2.0 |
Incoming Bandwidth | 80 Mbps |
Outgoing Bandwidth | 80 Mbps |
Chassis | 1U chassis |
Power Supply | 12VDC |
Power Consumption | <-18W |
Dimensions | 315 x 240 x 48mm |
Weight (Kg) | <-1Kg |
Working temperature | 10 degree C to +55 degree C, Working humidity: 10% to 90% |
Warranty | 1 year |
- Up to 8 channel IP cameras can be connected.
- Supports decoding H.265+/H.265/H.264+/H.264 video formats.
- Up to 4K high-definition live view, storage and playback.
- Up to 4-ch @ 1080p decoding capacity.
- Up to 80 Mbps high incoming bandwidth ensures IP cameras can be connected.
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output.
- 1 HDD for continuous video recording.
