Brand | WALTON |
Type | Direct Cool |
Capacity | |
Gross Volume | 157Ltr |
Gross Weight | 46 ± 2 Kg |
Net Volume | 144Ltr |
Net Weight | 41.5 ± 2 Kg |
Performance | |
Rated Operating Voltage | 220-240V~ |
Frequency | 50Hz |
Rated Voltage/Hz | 220~240v/ 50Hz |
Compressor Input Power (Watt) | V 0201- 107.5,V 0401- 82,V 0501/0502- 72,V 0601/0602- 81,V 0701- 72 |
Compressor Type | V 0201- RSIR,V 0401- RSCR,V 0501/0502- RSCR,V 0601/0602- RSCR,V 0701- RSCR |
Refrigerant | V 0201- R134a,V 0401- R134a,V 0501/0502- R600a,V 0601/0602- R600a,V 0701- R600a |
Condenser | V 0201-Copper,V 0401- Copper,V 0501/0502- MS,V 0601/06021- MS,V 0701- Copper |
Capillary | Copper |
stabilizer capacity | 600VA |
Cooling Effect | |
Freezer Cabinet | Less than -18℃ |
Refrigerator Cabinet | 0℃ to +5℃ |
General Features | |
Temperature Control | Mechanical |
Defrosting | Manual |
Handle | Recessed/ Grip |
Lock | Yes |
Thermostat | RoHS Certified |
Refrigerator Compartment | |
Shelf | Wire/2 |
Door Basket | PS/3 |
Interior Lamp | Yes |
Vegetable Crisper | Yes/1 |
Vegetable Crisper Cover | Yes |
Egg Tray or Pocket | Yes |
Freezer Compartment | |
Shelf (Material/ No.) | Wire/1 |
Dimensions (Net) | |
Width/mm | 512mm |
Depth/mm | 550mm |
Height/mm | 1425mm |
Packing | |
Width/mm | 555mm |
Depth/mm | 595mm |
Height/mm | 1475mm |
Loading Capacity- 40HQ/ 40Ft/ 20Ft | 112/112 /52 |
Residential Use:
- Replacement Guarantee 1 Year (Condition Apply)
- Main Parts (Compressor) 12 Years
- Spare Parts 4 Years
- After Sales Service 5 Years
Commercial Use:
- Main Parts (Compressor) 4 Years
- Spare Parts 2 Years
- After Sales Service 2 Years
Note:
This warranty does not cover the following cases
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.
2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
*Authority keeps the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
*This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
