PRODUCT DETAILS
Model | TAKYON 1.00 |
Top Speed | 50 Km/h |
Range | 60-70 Km |
Motor | 1.2 KW Hub Motor |
Battery | 72V 20Ah Graphene Lead Acid Battery |
DIMENSIONS | |
Length | 1860 mm |
Width | 715 mm |
Height | 1070 mm |
Wheel Base | 1320 mm |
Seat Height | 770 mm |
Ground Clearance | 130 mm |
WEIGHT | |
Curb Weight | 82 Kg |
Battery Weight | 40 Kg |
Maximum Loading | 180 Kg |
PERFORMANCE | |
Top Speed | 50 Km/h |
Range | 60-70 Km (25 Km/h) |
MOTOR | |
Type | DC Brushless |
Rated Power | 1.2 KW |
Maximum Power | 1.5 KW |
Torque | 85 N.m |
BATTERY | |
Battery Type | Sealed Lead Acid Battery |
Voltage | 72V |
Capacity | 20AH |
Battery Capacity (Wh) | 1440Wh |
Charging Cycle | 300-600 Charging Cycles |
Using Temperature | -20℃-60℃ |
Charger Input Voltage | AC 220V |
Charger Output Voltage | DC 72V |
Standard Charging Time | 8 Hours |
TIRE | |
Front Tire | 90/90-12, Tubeless Tire |
Rear Tire | 100/80-12, Tubeless Tire |
BRAKE | |
Front Brake | Disk |
Rear Brake | Disk |
SPEEDOMETER | LCD |
