| Brand | Walton |
| Type | Intelligent Inverter |
| Display Type | LCD |
| Basic Features | |
| Function | Cooling |
| Cooling Capacity | 3517 Watts (12000 BTU/h) |
| Compressor | Rotary (Inverter) |
| BTU/HR | 12000 |
| Rated Voltage | 220V-240V ~ 50Hz |
| Rated Input Power (W) | 690 |
| Rated Current (A) | 3.15 |
| COP | 5.1 |
| Cooling Features | |
| Cooling Capacity (W) | 3517 |
| Smart Control | Through App |
| Refrigerant | R-32 |
| Outdoor Operating Range (outdoor temperature) | 20˚C to 43˚C |
| Evaporator Fin Type | Louvered Fin |
| Condenser Type | Microchannel Condenser |
| Condenser Fin Type | Wave Fin |
| Maximum Pipe Length | 10m |
| Operations | |
| Turbo Mode (Maximum Cooling) | Yes |
| Auto Operation | Yes |
| Auto Restart | Yes |
| Dry Mode | Yes |
| Fan Mode | Yes |
| Speed Setting | Yes (Auto, High, Medium, Low) |
| Auto Restart | Yes |
| Timer | Yes |
| Health | Yes |
| ECO Mode (Power Saving) | Yes |
| Sleep | Yes |
| Operation/Control | Via IR (Infrared Ray) |
| Child Lock | Yes |
| Temperature Unit Change | Yes |
| Air Deflection | |
| Auto UP-Down Swing | Yes |
| Auto Left-Right Swing | Yes |
| Dimensions | |
| Indoor (mm) [LXWXH] | Unit: 1093 x 329 x 243 |
| Packing | 1180 x 410 x 315 |
| Outdoor (mm) [LXWXH] | Unit: 865 x 370 x 687 |
| Packing | 935 x 435 x 750 |
| Weights | |
| Net Weight (Indoor) (Kg) | 10.4 ± 0.5 |
| Gross Weight (Indoor) (Kg) | 12.2 ± 0.5 |
| Net Weight (Outdoor) (Kg) | 28.4 ± 1 |
| Gross Weight (outdoor) (Kg) | 32.3 ± 1 |
Guarantee Information
Product Replacement Guarantee: 1 Year
Note:
if there are manufacturing faults in heat exchanger & compressor.
For Residential Usage
-Compressor Warranty: 10 Years
-Spare Parts Support: 3 Years
-After Sales Service: 1 Year (Free)
For Commercial Usage
-Compressor Warranty: 5 Years
-Spare Parts Support: 2 Years
-After Sales Service: 1 Year (Free)
Terms & Conditions
1. This warranty does not cover the following cases -
i) The warranty will be invalid if the product is misused, neglected, rented on a commercial basis.
The warranty also will be invalid if repaired, replaced modified by an unauthorized service personnel.
ii) If the product serial number/barcode is removed, altered or duplicated, the warranty will be invalid.
2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
