| Brand | Walton |
| Type | Intelligent Inverter |
| Display Type | LCD |
| Basic Features | |
| Function | Cooling |
| Cooling Capacity | 5275 Watts (18000 BTU/HR) |
| Rated Voltage | 220V-240V ~ 50Hz |
| Rated Input Power (W) | Version 0608: 1570,Version 1008: 1570,Version 0611: 1710 |
| Rated Current (A) | Version 0608: 6.82,Version 1008: 6.82,Version 0611: 7.57 |
| COP | Version 0608: 3.35,Version 1008: 3.35,Version 0611: 3.08 |
| Cooling Features | |
| Compressor Type | Rotary (Inverter) |
| Refrigerant Type | Version 0608: R-32,Version 1008: R-32,Version 0611: R-410 |
| Refrigerant Amount (kg) | Version 0608: 0.920 kg, Version 1008: 0.920kg,Version 0611: 1.16 kg |
| Operating Range (Ambient Temperature) | 20˚C to 43˚C |
| Evaporator Fin Type | Louvered Fin |
| Condenser Type | Copper Condenser |
| Condenser Fin Type | Slit Fin |
| Maximum Pipe Length | 12m |
| Operations | |
| Turbo Mode (Maximum Cooling) | Yes |
| Auto Operation | Yes |
| Auto Restart | Yes |
| Dry Mode | Yes |
| Fan Mode | Yes |
| Speed Setting | Yes (Auto, High, Medium, Low) |
| Auto Restart | Yes |
| Timer | Yes |
| Health | Yes |
| ECO Mode (Power Saving) | Yes |
| Sleep | Yes |
| Child Lock | Yes |
| Temperature Unit Change | Yes (160C to 310C) |
| Remote & Air Deflection | |
| Operation/Control | Via IR (Infrared Ray) |
| Auto UP-Down Swing | Yes |
| Auto Left-Right Swing | Yes |
| Dimensions | |
| Indoor (mm) [LXWXH] | Unit: 942 x 321 x 238 |
| Packing | 1025 x 400 x 300 |
| Outdoor (mm) [LXWXH] | Unit: 844 x 310 x 546 |
| Packing | 900 x 372 x 610 |
| Weights | |
| Net Weight (Indoor) (Kg) | 12.5 ± 0.5 |
| Gross Weight (Indoor) (Kg) | 15 ± 0.5 |
| Net Weight (Outdoor) (Kg) | Version 0608: 26.5 ± 1,Version 1008: 26.5 ± 1,Version 0611: 29 ± 1 |
| Gross Weight (outdoor) (Kg) | Version 0608: 31 ± 1,Version 1008: 31 ± 1,Version 0611: 33 ± 1 |
Guarantee Information
Product Replacement Guarantee: 1 Year
Note:
if there are manufacturing faults in heat exchanger & compressor.
For Residential Usage
-Compressor Warranty: 10 Years
-Spare Parts Support: 3 Years
-After Sales Service: 1 Year (Free)
For Commercial Usage
-Compressor Warranty: 5 Years
-Spare Parts Support: 2 Years
-After Sales Service: 1 Year (Free)
Terms & Conditions
1. This warranty does not cover the following cases -
i) The warranty will be invalid if the product is misused, neglected, rented on a commercial basis.
The warranty also will be invalid if repaired, replaced modified by an unauthorized service personnel.
ii) If the product serial number/barcode is removed, altered or duplicated, the warranty will be invalid.
2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
