Brand | Asus |
Model | Asus ROG STRIX B460-H GAMING |
CPU | |
Chipset Brand | Intel |
Chipset | Intel B460 |
Sockets Supported | LGA1200 |
Supported CPU | 10th Generation Intel Core i9 / i7 / i5 / i3 / Pentium Gold / Celeron Processors |
Generation | 10th |
Memory Support | |
Memory Type | DDR4 |
Memory MHz | 2933/ 2800/ 2666/ 2400/ 2133 MHz |
Memory Channel | Dual |
Memory Slot | 4 |
Memory Max. | 128GB |
Optane Memory Support | Yes |
Storage | |
Storage Interface | 6.0Gb/s |
M.2/SSD Expansion Slot | 2 |
Graphics | |
Graphics | Integrated Graphics |
Multi-GPU Support | 2-Way AMD CrossFireX Technology |
PCI Express Slot | 1 PCIe 3.0 x 16, 3 PCIe 3.0 x 1 |
Audio & Video | |
Audio Chipset. | ROG SupremeFX |
Audio Channel | 7.1 |
Network & Connectivity | |
LAN Chipset | Intel I219-V |
LAN Speed (Mbps) | 10/100/1000 |
Ports | |
USB Port | 1 x USB 3.2 Gen 2x2 Type-C, 7 x USB 3.2 Gen 1, 2 x USB 2.0 |
HDMI Port | 1 |
SATA Port | 6 x SATA |
Thunderbolt | 1 |
Technical Information | |
CrossFire Support | Yes |
Raid Support | 0, 1, 5, 10 |
RGB Support | Yes |
RGB Sync | Aura sync |
RGB Connector | 1 x Aura RGB Strip Headers |
Form Factor | ATX |
Bios Information | |
BIOS Type | 128 Mb Flash |
BIOS Model | AMI UEFI BIOS |
Compatibility | |
Supported Operating System | Windows 10 |
Warranty | |
Warranty | 3 Years Replacement Warranty |
Additional Info | |
Feature | ROG Strix B460-H Gaming motherboard is instantly recognizable with its classic red-and-black color scheme and futuristic cybertext markings. It is packed with all the essentials, including robust hardware and intuitive ROG software to make it ideal for gamers and builders of all levels. Extreme Engine Digi+, 5K Black Metallic Capacitors, ASUS Q-Design: ASUS Q-DIMM, ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]), ASUS Q-Slot, ASUS Thermal Solution: Aluminum M.2 heatsink, ASUS EZ DIY: BIOS FlashBack button, BIOS FlashBack LED, Procool, Pre-mounted I/O shield, SafeSlot, AURA Sync: Standard RGB header(s), Addressable Gen 2 RGB header(s), Rear audio USB Type-C connector |
Others | 1 x Intel I219-V 1Gb Ethernet, 1 x DisplayPort, 1 x Optical S/PDIF out 5 x Audio jack(s), 1 x CPU Fan connector(s), 1 x CPU OPT Fan connector(s), 2 x Chassis Fan connector(s), 1 x AIO_PUMP connector, 1 x AAFP connector, 1 x Aura RGB Strip Headers, 1 x Addressable Gen 2 header(s), 1 x Thunderbolt header(s), 1 x 24-pin EATX Power connector(s), 1 x 8-pin ATX 12V Power connector(s), 1 x System panel connector |
Maximum ram supports 128GB. Also, you can use 2 M.2/SSD Expansion Slot. Storage Interface is 6.0Gb/s. Buy Asus ROG STRIX B460-H GAMING + Motherboard comes with Integrated Graphics. PCI Express Slot are 1 PCIe 3.0 x 16, 3 PCIe 3.0 x 1. The here audio chipset used ROG SupremeFX. Audio Channel available are 7.1, so you can enjoy crystal clear sound.
For Network and Connectivity purposes the Asus motherboard offers Intel I219-V lan chipset and it’s speeds 10/100/1000. USB port available 1 x USB 3.2 Gen 2x2 Type-C, 7 x USB 3.2 Gen 1, 2 x USB 2.0. Also, you will get VGA Port, DVI Port,HDMI Port, SATA Port and TPM Port. . It’s a ATX motherboard. Yes it’s a RGB support motherboard, also you can 1 x Aura RGB Strip Headers RGB connector. The Buy Asus ROG STRIX B460-H GAMING + Motherboard supported operating system is Windows 10. You will get a 3 Years Replacement Warranty brand warranty.
